Мрежна опрема CUDY SKU 17716

NET ACCESS POINT CUDY AP1300E WALL, Gigabit Ethernet PoE, AP1300E WALL

Бесплатна достава на залиха

2.770 ден

Цена за Pro членови 2.430 ден Заштеда340 ден. Активирај PRO
Сакаш дополнителен попуст? Стани член со активирање на PRO членство!
Бесплатна достава за скоро сите производи Безбедна нарачка плаќање со картичка Поддршка [email protected]

SKU 17716
Категории
Мрежна опрема
Брендови
CUDY
Тагови
CUDY neksio

Опис

Model Name: AC1200 86mm Wall-Plate Wi‑Fi Access Point AP1300E Wall 1.0

AC1200 dual‑band wall‑plate access point · 4‑stream Wi‑Fi 5 (867 + 300 Mbps)
PoE 802.3at/af & passive PoE · Covers up to 50 m² · Up to 40 connected devices

Features

  • AC1200 4‑stream dual‑band Wi‑Fi 5 with speeds up to 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz)
  • Wall‑plate design (86 mm) ideal for hotels, offices, and apartments
  • Coverage up to 50 m² (540 ft²) and support for around 40 connected devices
  • Powered via PoE with 1 × GbE PoE in (ETH0) and 1 × GbE LAN port
  • Supports 802.3at/af PoE and 48 V passive PoE for flexible deployment
  • Built‑in watchdog and schedule reboot for improved reliability and uptime
  • Multi‑AP management support for centralised configuration and monitoring
  • LED on/off and Wi‑Fi control button plus reset button for easy local management
  • Optimised RF design with internal antennas and beamforming for better range through walls

Specification

  • Product type: Wall‑plate Wi‑Fi access point
  • Wi‑Fi standard: IEEE 802.11ac / Wi‑Fi 5, dual band
  • Wi‑Fi class: AC1200 (4‑stream)
  • 5 GHz Wi‑Fi speed: 867 Mbps
  • 2.4 GHz Wi‑Fi speed: 300 Mbps
  • 5 GHz Wi‑Fi streams: 2 spatial streams
  • 2.4 GHz Wi‑Fi streams: 2 spatial streams
  • Wi‑Fi antennas: 4 × internal
  • 5 GHz antenna gain (max): 4.5 dBi
  • 2.4 GHz antenna gain (max): 3.5 dBi
  • FEM / PA/LNA: 5 GHz – 2 × internal; 2.4 GHz – 2 × internal
  • Beamforming: Yes
  • Coverage (typical): Up to 50 m² (540 ft²)
  • Range performance (max): Up to 80 m (262 ft) in open space
  • Wall performance: Two wooden walls < 10 cm, or one concrete wall < 20 cm
  • Recommended clients: ~40 connected devices
  • CPU: 880 MHz dual‑core
  • Flash / ROM: 16 MB (128 Mbit) NOR
  • DDR / RAM: 128 MB (1 Gbit) DDR3
  • Ethernet ports: 2 × Gigabit RJ45
  • PoE port: ETH0 accepts PoE powering
  • LED indicators: System
  • Buttons: Reset button; LED On/Off button (configurable to control LED and Wi‑Fi)
  • Power input type: PoE via Ethernet port
  • Power methods: 802.3at/af PoE, 48 V passive PoE
  • PoE input: 802.3at/af or 48 V passive PoE
  • Max power consumption: 10 W (PoE)
  • Idle power consumption: 4 W
  • Operating temperature: 0–40 ℃ (32–104 ℉)
  • Storage temperature: -40–70 ℃ (-40–158 ℉)
  • Operating humidity: 10–90% RH (non‑condensing)
  • Storage humidity: 5–90% RH (non‑condensing)
  • Dimension: 86 mm wall‑plate form factor (exact mm not specified beyond panel size)
  • Management features: Watchdog, Schedule reboot, Multi‑AP management
